ELMARK Irányváltó kontaktor, LT4-D9511, 95A, 230V

<p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br /> (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p><p><strong>Technical characteristics:</strong><br />- Rated current: 18-95А<br />- Operaton class : АС3<br />- Rated operating voltage of the controlling coil: 230V АC;50/60Hz<br />- Rated operating voltage of the power circuit: up to 690V АС<br />- Insulation voltage: 690V<br />- Surge voltage wear resistance: >8000V<br />- Number of contacts: 3 NO power contacts +1NO operative <br />  (for contactors over 40А there is also additional 1NC contact)<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles): ≥10000000<br />- Number of cycles (switching on) per hour: up to 600 <br />- Ambient temperature : -10° to 65ºС<br />- Maximum altitude: 2000m</p>n<p><strong>Advantages:</strong><br />- Material: resistant to UV rays, self-extinguishing<br />- Switching ON of electrical motors in one direction of rotation and turning (reversing) of the rotation direction at outside command.<br />- No option for simultaneous switching ON of the two contactors in the group due to mechanical interlock <br />- High reliability of the current parameters<br />- Secure separation of the power contacts<br />- Easy mounting <br />- Long life</p>n<p><strong>Functions:</strong> <br />- The contactor is used for reverse control of inductive motor with short circuited rotor <br />- Developing of control systems</p>n<p><strong>Applications:</strong><br />- Industry<br />- Services</p>n<p><br /><strong>Mounting:</strong> On a DIN rail or using bolts to flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1; EMC; LVD</p>
