Főkategória >Ipari kapcsolók >Kontaktorok és kiegészítőik >Elmark kontaktorok és kiegészítőik



ELMARK kontaktor, 65A, 48V, 1Z+1NY

ELMARK kontaktor, 65A, 48V, 1Z+1NY
Energiaosztály 2023-
Listaár: 25 834 Ft
15 501 Ft
Díjmentes szállítás!
db Kosárba Kosárba
RAKTÁRON



ELMARK elektronikai katalógus 2026 1.rész



ELMARK elektronikai katalógus 2026 2.rész



ELMARK világítástechnikai katalógus 2026 1.rész



ELMARK világítástechnikai katalógus 2026 2.rész



ELMARK elektronikai katalógus 2025



ELMARK világítástechnikai katalógus 2025



- A kép illusztráció!



ELMARK elektronikai katalógus


ELMARK világítástechnikai katalógus


ELMARK 23656 általános leírása:

Az ipari kapcsolók nélkülözhetetlen elemei a modern gyártási folyamatoknak és automatizálási rendszereknek. Ezek a mechanikus vagy elektronikus eszközök feladata, hogy vezéreljék az elektromos áramot különböző berendezésekben és gépekben.



Az ipari kapcsolók széles választékban kaphatók, és számos különböző típusuk létezik. A leggyakoribb típusok közé tartoznak:
* Motorkapcsolók: Speciálisan motorok indítására és leállítására tervezett kapcsolók.
* Teljesítménykapcsolók: Nagy teljesítményű áramkörök kapcsolására szolgálnak.
* Biztonsági kapcsolók: Biztonsági funkciókat látnak el, például vészleállítást vagy ajtózárást vezérelnek.
* Hőmérséklet-kapcsolók: Hőmérsékletváltozás hatására kapcsolnak.
* Szintkapcsolók: Folyadékszint vagy szilárd anyagok szintjének érzékelésére és kapcsolásra szolgálnak.
* Nyomáskapcsolók: Nyomásváltozás hatására kapcsolnak.



Az ipari kapcsolók jellemzői
* Kapcsolási teljesítmény: Az a maximális áram, amelyet a kapcsoló képes megszakítani.
* Kapcsolási feszültség: A maximális feszültség, amelyet a kapcsoló képes kezelni.
* Élettartam: A kapcsoló működési ciklusainak száma meghibásodásig.
* Védettség: A kapcsoló védettsége a környezeti hatásokkal szemben (por, nedvesség, ütések).
* Kapcsolat típusa: Normál nyitott vagy normál zárt kapcsolat.
* Működtetési mód: Kézi, automatikus vagy távvezérlésű.



Az ipari kapcsolók felhasználási területei
Az ipari kapcsolók széles körben alkalmazhatók különböző iparágakban, például:
* Gyártás: Gépek, berendezések vezérlése, automatizálás.
* Energetika: Áram elosztása, védelem.
* Épületgépészet: Fűtés, szellőzés, légkondicionálás.
* Automatizálás: Robotika, PLC-k.



Egyéb információk
* Anyagok: Az ipari kapcsolók általában fémötvözetekből, műanyagokból és kerámiákból készülnek.
* Szerelés: Az ipari kapcsolók különböző szerelési módokkal rendelkezhetnek (panelre szerelhető, DIN sínre szerelhető stb.).
* Biztonság: Az ipari kapcsolók kiválasztásakor kiemelt figyelmet kell fordítani a biztonságra. A megfelelő védettségű és minősített kapcsolókat kell választani.
* Karbantartás: Az ipari kapcsolókat rendszeresen ellenőrizni és karbantartani kell ajánlott 8-10 évente cserélni.

További információért keressen minket bizalommal: info@gazdafielectronic.hu
Részletek Kiegészítő termékek Adatok Vélemények
  • <p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br /> 6-32А - 1200cycles<br /> 40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p><p><strong>Technical characteristics:</strong><br />- Operation class: АС-3<br />- Rated current: 6-95А<br />- Rated operating voltage of power contactors: up to 690V; 50/60Hz <br />- Surge voltage wear resistance: >8000V<br />- Rated operating voltage of the coil: 12/24/36/48/110/230/400<br />- Electrical wear resistance (number of cycles): ≥1000000<br />- Mechanical wear resistance (number of cycles):≥10000000<br />- Number of cycles (switchings ON) per hour: <br />   6-32А - 1200cycles<br />   40-95А - 600cycles<br />- Pole leaking power: up to 13W<br />- Ambient temperature: -10°÷60ºС<br />- Maximum altitude: up to 2000m</p>n<p><br /><strong>Mounting:</strong> on a DIN rail or using bolts to a flat surface in a vertical position with maximum gradient of ±5°</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-4-1</p>
  • Gyártó
    ELMARK
    Energiaosztály 2023-
    -
    Garancia
    5+2
    Gyártói cikkszám
    23656
    Névleges áram
    65A
    Névleges áramerősség (In)
    65A
    Segédérintkezők
    1Z+1NY
    Súly
    1.218
    Tekercsfeszültség
    48V
    Típus
    LT1-D6511 1NO+1NC
    Vonalkód / EAN-kód
    3800131108456
    márka
    ELMARK
    A mágneskapcsoló típusa
    D
    A tekercs típusa
    Váltakozó áram
