Főkategória >Ipari kapcsolók >Terhelésszakaszolók >Elmark terhelésszakaszolók



ELMARK szakaszolókapcsoló, ISS2-250in, 3P, 250A, 660V

ELMARK szakaszolókapcsoló, ISS2-250in, 3P, 250A, 660V
Energiaosztály 2023-
Listaár: 34 776 Ft
20 866 Ft
Díjmentes szállítás!
db Kosárba Kosárba
RAKTÁRKÉSZLET FEJLESZTÉS ALATT



ELMARK elektronikai katalógus 2026 1.rész



ELMARK elektronikai katalógus 2026 2.rész



ELMARK világítástechnikai katalógus 2026 1.rész



ELMARK világítástechnikai katalógus 2026 2.rész



ELMARK elektronikai katalógus 2025



ELMARK világítástechnikai katalógus 2025



- A kép illusztráció!



ELMARK elektronikai katalógus


ELMARK világítástechnikai katalógus


ELMARK 41955 általános leírása:

Az ipari kapcsolók nélkülözhetetlen elemei a modern gyártási folyamatoknak és automatizálási rendszereknek. Ezek a mechanikus vagy elektronikus eszközök feladata, hogy vezéreljék az elektromos áramot különböző berendezésekben és gépekben.



Az ipari kapcsolók széles választékban kaphatók, és számos különböző típusuk létezik. A leggyakoribb típusok közé tartoznak:
* Motorkapcsolók: Speciálisan motorok indítására és leállítására tervezett kapcsolók.
* Teljesítménykapcsolók: Nagy teljesítményű áramkörök kapcsolására szolgálnak.
* Biztonsági kapcsolók: Biztonsági funkciókat látnak el, például vészleállítást vagy ajtózárást vezérelnek.
* Hőmérséklet-kapcsolók: Hőmérsékletváltozás hatására kapcsolnak.
* Szintkapcsolók: Folyadékszint vagy szilárd anyagok szintjének érzékelésére és kapcsolásra szolgálnak.
* Nyomáskapcsolók: Nyomásváltozás hatására kapcsolnak.



Az ipari kapcsolók jellemzői
* Kapcsolási teljesítmény: Az a maximális áram, amelyet a kapcsoló képes megszakítani.
* Kapcsolási feszültség: A maximális feszültség, amelyet a kapcsoló képes kezelni.
* Élettartam: A kapcsoló működési ciklusainak száma meghibásodásig.
* Védettség: A kapcsoló védettsége a környezeti hatásokkal szemben (por, nedvesség, ütések).
* Kapcsolat típusa: Normál nyitott vagy normál zárt kapcsolat.
* Működtetési mód: Kézi, automatikus vagy távvezérlésű.



Az ipari kapcsolók felhasználási területei
Az ipari kapcsolók széles körben alkalmazhatók különböző iparágakban, például:
* Gyártás: Gépek, berendezések vezérlése, automatizálás.
* Energetika: Áram elosztása, védelem.
* Épületgépészet: Fűtés, szellőzés, légkondicionálás.
* Automatizálás: Robotika, PLC-k.



Egyéb információk
* Anyagok: Az ipari kapcsolók általában fémötvözetekből, műanyagokból és kerámiákból készülnek.
* Szerelés: Az ipari kapcsolók különböző szerelési módokkal rendelkezhetnek (panelre szerelhető, DIN sínre szerelhető stb.).
* Biztonság: Az ipari kapcsolók kiválasztásakor kiemelt figyelmet kell fordítani a biztonságra. A megfelelő védettségű és minősített kapcsolókat kell választani.
* Karbantartás: Az ipari kapcsolókat rendszeresen ellenőrizni és karbantartani kell ajánlott 8-10 évente cserélni.

További információért keressen minket bizalommal: info@gazdafielectronic.hu
Részletek Kiegészítő termékek Adatok Vélemények
  • <p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p><p><strong>Technical characteristics:</strong><br />- Rated operating voltage: not higher than 660V; 50/60Hz<br />- Rated current: 125-800А<br />- Insulation voltage: ≥1000V<br />- IP code: IP>20<br />- Number of poles:3,4<br />- Operating temperature: -20°÷65ºС</p>n<p><br /><strong>Advantages:</strong><br />- High mechanical endurance and wear resistance<br />- Resistant to high voltages<br />- Easy mounting and control<br />- Long life<br />- High reliability</p>n<p><br /><strong>Functions:</strong><br />- As a main circuit breaker in energy distribution <br />- Designed for mounting in main electrical boards for disconnection of the circuits<br />- Switching ON of generators as they are not affected by the frequency variations</p>n<p><strong>Applications:</strong><br />- Industry<br />- Administrative a nd residential buildings</p>n<p><strong>Standards:</strong> EN60947-1; EN60947-3</p>
  • Gyártó
    ELMARK
    Energiaosztály 2023-
    -
    Garancia
    5+2
    Gyártói cikkszám
    41955
    Névleges áram
    250A
    Névleges áramerősség (In)
    250A
    Névleges feszültség
    660V
    Névleges feszültség (Un)
    660V
    Névleges lökőfeszültség-állóság (Uimp)
    8000V
    Névleges szigetelési feszültség (Ui)
    1000V
    Névleges zárlati határ-megszakítóképesség (Icu)
    2000A
    Pólusok száma
    3
    Pólusok száma
    3
    Súly
    2.250
    Típus
    ISS2-250in
    Vonalkód / EAN-kód
    3800131123725
    márka
    ELMARK
    Modell
    ISS2
